The "Best"
Audio Interface
for your Home Studio


Soundcards and Interfaces   1    2    3    4    5    6


How to buy an audio interface intelligently

by the Tweak

The Bell rings, a fresh class of newbies usher in, eager to get started with digital recording. "My goal", starts Tweak, his quiet voice trying to rise above the hub-bub, "is to keep you from making a serious mistake".

"And save you money".  A hush falls over the crowd.

PreSonus FireStudio Mobile FireWire Audio Interface

The Firestudio Mobile is a ten-input, six-output professional recording system that combines two PreSonus XMAX(TM) Class A microphone preamplifiers; six line-level, analog input channels; S/PDIF digital input and output; MIDI I/O; and headphone monitoring with separate gain control. The FireStudio Mobile beats any and all competition when it comes to flexibility and input count. You can record a whole band with the FireStudio Mobile.  Tweak:  Impressive i/o for the money.

Tweak: If you need 8 preamps and want the motorized fader automation, check out  the Tascam FW1884

But you should know, up front:  No matter what you choose, there will always be a risk that it won't work well on your system.   Every computer is a unique environment of hardware and software, and one bad variable can make a $700 audio interface sound worse than an ancient AWE32.  If you get advice from me or anyone on the forums use that knowledge entirely at your risk, OK? OK!

Ok, lets go. People ask me all the time, "What's the best soundcard for my studio".  You know, that's like asking someone what is the best car on the market, or which all night restaurant has the best coffee. "Best" is a 4 letter word; please don't ask me what's best, even if you can afford it (We'll start you with an Apogee Native Tools which lists about 8 grand).  There is no universally acclaimed best soundcard. Best for what? PCs? Macs? For running Sonar? Cubase? For a pristine 3.6ghz 64 bit DAW or a lowly Pentium III 550? For a computer that has the notorious VIA motherboard chipset? For under $200? $500? $1500. For Win XP before SP2?  For Mac OS 10.39 or OS 10.4?

Even with all that information, is there a definitive answer out there?  Not really. Unless someone is whacked enough to buy every soundcard in existence, test them all on every OS/CPU configuration and have enough sanity left to recall the results.  But we can steer you towards some of the better choices available today, armed with that info.

Audio Interface or Soundcard?

Over the past few years, musicians have been opting for audio interfaces over standard soundcards.  These may be either PCI or Firewire.  The AI typically has a breakout box that sits outside the computer and a cable that is connected to either a PCI card in the computer or a USB or Firewire cable.  On this breakout box are a number of connectors for cables that go to your instruments, mics, mixer or monitoring system.  The conventional soundcard, on the other hand, just sits in the computer in a PCI slot, the cables hang off the back of the card.

The audio interface type of system is often preferred because the cables stay away from the fierce electrical fields that surround the modern computer. True? Well, that argument does not hold a lot of water, and it doesn't bother the guys running hi-end RME and Lynx cards. But this argument does...

Tweak crawls under the desk in the classroom and lays on his back, pulls out a flashlight, rips off his glasses pulls out a magnifying glass and shouts out "How in the bloody heck are you supposed to read which is "In" and "Out" on this thing?".

Ha! With a breakout box you don't have to lay on the floor under some desk to connect it up and you can move your noisy computer farther away--always a good idea when recording audio.





The MOTU 828mk3 is a Firewire Audio Interface, plenty of i/o, great Mac OSX drivers.


Audio interfaces also sometimes allow for balanced audio connectors instead of the unbalanced 1/8" stereo jacks one sees on most cards.  If you want the cleanest possible recordings, then go with an audio interface that has balanced connectors.  We'll get into that on page 2.  For now, just note that balanced does make a difference, particularly if you need to run cables longer than 10-12 feet.

Full-Featured Home Studio Interfaces that let you connect a lot of gear.

Tweak's Pick for PC

Tascam FW1884   Tweak:  You get everything you need.  Firewire interface, plenty of analog i/o, preamps, MIDI ports galore and a control surface to track the software mixer. You can upgrade the system with stand alone preamps and converters and there is an FE-8 expander to add an additional 8 channels to the control surface.  It will work on a Mac too.

Tweak's Pick for Mac

Mark of the Unicorn (MOTU) 828MK3 Firewire 24/96 Audio Interface Tweak: MOTU interface have long been regarded as the ideal "Mac" interfaces.  But now PC users report success as well.  It is my pick for my Mac and I have reviewed the 828mk2 extensively.  I love it!  Great for LogicPro. The 828mk3 will also work on a PC and has a firewire and USB 2.0 version.

See more in my article Audio Interfaces for your Mac

Tweak's Pick for the Pro

RME Fireface 800 Firewire Audio Interface
After more than 2 years of development, the time has come: RME presents the Fireface 800, the world's most powerful FireWire audio interface ever. Up to 56 channels record/playback, up to 192 kHz sample rate, and true FireWire 800 sum up to an unsurpassed high-end, high performance and high speed FireWire audio interface.

Mark of the Unicorn (MOTU) 24IO 24-Channel Audio Interface
The MOTU Audio 24I/O interface fulfills the promise of host-based hard disk recording: to record, edit, mix process, and master multi-track recording projects entirely inside the computer. It provides 24 high quality, 24-bit/96kHz analog inputs and outputs in a cost effective, single rack space package, allowing you to connect and record from 24 simultaneous analog sources.


Shopping for an interface?  See my PCI and Firewire Comparison Charts that compare lots of different Units

Browse Audio Interfaces and Soundcards by Type in Tweak's Audio Interface Showroom


Technology Alert: Namm 2006

There are now alternatives to getting a soundcard or audio interface.  There is a new breed of firewire and USB based mixers that can be used to get audio to your computer.  Look at the Mackie Onyx, Alesis MultiMix Firewire, and the Behringer XENYX.

Also take a look at the M-Audio Project Mix

Technology Alert:  Namm 2007

USB 2.0 interfaces are finally starting to come online.  Check out the Emu 0202, 0404, the Tascam US 144 and the Alesis IO2.  See my chart of the USB 2.0 interfaces

Technology Alert
Namm 2008

Probably one of more noteworthy developments is that audio interfaces are appearing on products that never used to have one.  Mixers, keyboard controllers, workstations, and even microphones may now have a simple 2x2 audio interface tacked on. How many audio interfaces do you need?  One!  Make it a good one, not something added on to a guitar multi effects pedal.

There were relatively few new audio interfaces since Namm 2007.  Presonus updated their line with the new Firestudio series.  Tascam has a new USB 2.0 interface the US1641, which has great i/o for under $400  Motu released the successor the the 828mk2 with, you guessed it, the Motu 828mk3 and some other MOTU interfaces as well

Technology Alert
Namm 2009

So what's going to happen?  I think Mixers are about to be come more intelligent and will soon come with integrated  big audio interfaces. Currently these exist but start around 3k. But you should know that audio interfaces are already at a high state of the art.

Another thing that has happened:  Apple has dumped Firewire on its low end laptops.  Then they came out with cheaper Mac Book Pros. The Mac Pros and Macbook pros still have Firewire 800.  FW 400 interfaces will still work on a FW 800 port if you have the right cable. But low end Macbooks are forced to use USB2.0 audio interfaces.  This has caught the industry with its pants down.


Digital Audio Converters

There are two parts to every audio interface/card that affects the sonic performance profoundly.  The first are the software drivers that come with the card.  The second is the quality of the digital audio converters (DACs) that are physically on the card. Audio interfaces may have mic preamps, and these to can affect the quality of your recordings.  We're going to talk about all these elements.  But first, lets get to the DACs.

Time Out:  If you have an audio interface do you need a soundcard too?


Answer: No.  The audio interface will take care of all of the computer's audio functions. A PCI audio interface comes with a breakout box and its own PCI card.  The Firewire audio interface does not need a card at all.

Most soundcards on the market have acceptable quality DACs these days, compared to a few years ago when you had to spend premium dollars to get good DACs.  It makes sense if you think of your CD player when thinking of the quality of DACs.  Early cd players had a harsh sound to them and were often considered "brittle".  As a result of that criticism, audio engineers found ways to make the DACs sound better, with oversampling, error correction, interpolation and other ways to "smooth" the output.  At the core of the DAC is a process called "sampling".  The converter "reads" the analog incoming waveform and transforms it into numbers, or data.  Once it is data, the computer can manipulate it in many different ways, store it on disks, merge it with other data, and so on.

The DAC determines how good the card sounds. Whether a card is USB, Firewire or PCI does not affect the sound per se. These are just methods of shuttling data. The DACs actually touch the sound. But there is more to a quality soundcard than just the DACs...


Someone shouts from the back row, "Tweak, dude, just tell me who has the best DACs so i can buy my card!"  (Tweak suddenly turns red and veins start popping out of his tweakly neck) Hmm, there's that "best", that 4-letter word again, his voice rising to creshendo.  "OK class, Mr. Newbie "gotsta know right now" wants to know the best DAC, can anyone help him?"  Someone shouts out "Pro Tools!" Tweak ejects the person from the classroom like an umpire at the world series.  The class nervously squirms as Tweak paces the aisles of the class. Anyone else want to answer that one? The someone in the front stands up and says: "The point is you can't hear a DAC without the audio going through a software driver.  If a card has a great DAC and a crap driver it is a worthless card"  Tweak smiles in delight and gives the speaker a gold star.  Someone else shouts "Hey, that's not cool if soundcard makers actually release cards with crummy drivers, do they really do this Mr. Tweak?  The Tweak looks down, searching for the politically correct words.  Someone else yells out "Yes they do!"  [I didn't say that.]

Professionals that are concerned with the quality of digital analog conversion will buy an outboard DAC that connects to a soundcard's digital input/outputs. These effectively bypass the DACs on the soundcard.  When you need the absolute highest quality, you bite the bullet and add outboard converters, which you can add at any time to any soundcard or interface that has s/pdif (digital i/o).  Read more about digital audio converters.  Can you do listening tests on these DACs?  Yes, but like all tests of this nature, your ultimate assessment is subjective.   Also, to hear the difference you need superb monitors and a squeaky clean signal path.  That being said, record a full mix and then record just its cymbal track.  Listen to the quality of the cymbals alone, and then again in the mix.  The DAC that best preserves the hi frequency shimmer and definition without smearing or artifacts can be considered better, given the rest is equal.  This is one of the 1st places a bad DAC will mess up. You might also want to evaluate on the basis of warmth, fluidity and whether your ears "like" the sound.

Ok, I know a lot of you are going to want to get the card with the "best" DACs like Mr. Noob above.  It might even make you sweat before a purchase, and sway you to pick an interface you would not otherwise.  You are better off getting the card you want for its i/o and drivers.  You can always add DACs later, and they will be better than the ones on nearly all of the soundcards and interfaces.  After you get your monitors and maybe one hi end preamp, then you should start thinking about converters.  Until you get those items, you won't hear that much difference.  If you absolutely need great DACs on your soundcard/interface, consider the RME Fireface.


Drivers can cause your recording application to CRASHSo what is a software driver, and how does it affect audio performance? The driver is the critical code that manages the traffic of data going from the cpu to and from the DAC. It organizes the data so the CPU can fetch it when the audio application says it is needed.  There are certain rules the driver has to follow that are set by the operating system.  The application and the CPU have to follow the rules, and if the driver interprets the rules properly, all will work.  If there is a flaw on the application side or the driver side, things are going to mess up.  If the poor CPU can't get the data the 1st time, it might try again.  And Again.  And Again.  What just happened to your audio, dude, it stopped?  "CPU overload, eh?"  Wonder why companies are often finger pointing at each other when users protest?  Hehe  "Company Z's driver is is garbage", or "The problem is in Company X's application, we asked them to fix it but they have not responded".  Sound Familiar?

Drivers are very hard to perfect. What might work great on some machines, work's terribly on others. This is what makes the decision so maddening. If you are on a PC and Microsoft introduces a new OS, or changes direct X, then your soundcard may stop working well. It's like building a house in an area that has an earthquake every 3 years or so.  Some motherboards actually get in the way of audio flowing to the CPU and if the driver is not aware of these issues, the audio will get hurt.




So what does this mean in terms of buying a soundcard or audio interface?

It means to look for evidence that the product

1. Has a driver for your OS. Never assume it does.

2. Has a driver that claims it works with your application, like Logic, Cubase SX or Sonar.

3. Has a site where you can download drivers

4. Has an updated driver within the last 6 months and supports the latest service packs and OS updates.

5.  Looks like driver development is something they take seriously for your computer platform.  A company may make great cards for PC and say "we have a Mac driver too!"

6. Looks like they have a cooperative relationship with software makers, with product bundles.


It's all too common for new products to have driver issues. Avoid the latest stuff that came out last week. It irritates me that hardware makers sometimes release products before the drivers are ready.  Don't hesitate to return products that do this, if you downloaded the latest update and it still bugs out. (By the by, zZounds has an excellent, easy return policy).  But always download the latest driver when you get your interface.  Did I just say "always?" Yes I did!  Do it!


OK. you doin' OK?  I know some of this is tough, but I have to set you up right, so you really know this stuff.  On the next page we'll talk about the preamps on audio interfaces and then talk about the different ways they shuttle your data around.  You'll also get my little crib notes on nearly every audio interface on the market.


Soundcards and Interfaces   1    2    3    4    5    6

On to the Next Page
